| BASIC INFO |
| Model No. |
WinPad W106 |
| Operating system |
Windows 10 Home |
| Dimension |
280*187*22 mm |
| Weight |
Device unit: 1014g, Docking: 290g |
| Color |
Black, silver |
| Languages |
Multi-language (English default) |
| HARDWARE |
| Display |
10.1-inch anti-scratch Corning Gorilla III capacitive touch screen, 1920*1200px, 400 nits |
| Processor |
Intel Cherry Trail Z8350 quad-core, 1.44GHz-1.92GHz; GPU: Intel HD Graphics |
| RAM |
4 GB DDR3L |
| ROM |
64 GB ROM (128 GB optional), support TF card up to 128 GB maximally |
| Camera |
Double cameras: rear 5MP with flash, front 2MP |
| Battery |
Removable 3.7V/10,000mAh lithium polymer battery |
| Gravity sensor |
Support |
| Speaker |
8 Ω/0.8W waterproof speaker *1 |
| Mic |
Support |
| NETWORK & CONNECTIVITY |
| Bands |
2G: GSM 850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1900/2100MHz |
| 4G: FDD-LTE B1/B/2/B3/B4/B5/B7/B8/B20 |
| Wi-Fi |
IEEE 802.11 a/b/g/n, support 2.4GHz+5.8GHz dual-band Wi-Fi |
| BT |
V4.1 |
| GNSS |
Support GPS/GLONASS/QZSS |
| I/O INTERFACES |
| TF card slot |
*1 |
| USB 2.0 port |
*1 |
| 3.5 mm Audio jack |
*1 |
| DC-IN port |
*1 |
| HD-MI 1.4a Type-C |
*1 |
| 12pin Pogo Pin |
*1 |
| RS232 (DB9 port) |
*1 |
| RJ45 Port |
*1 |
| OPTIONAL FEATURES |
| Fingerprint identification |
Optional |
| 1D Barcode scanning |
Optional |
| 2D Barcode scanning |
Optional |
| NFC |
Optional |
| RELIABILITY |
| Waterproof |
IP65 |
| Drop-proof |
100 cm composite wood floors, in operation status |
| Explosion protection |
Ex ic IIB T4 Gc |
| Temperature range |
Operating: -10℃~ 50℃ Storage: -30℃~70℃ |
| Humidity range |
95% Non-condensing |
| ACCESSORIES |
| OTG Cable |
*1 |
| Charger |
*1 |
| Power Adaptor |
*1 |
| Wrist Strap |
*1 |
| Docking Charger |
Optional |
| Car Holder |
Optional |
