UNIWA D2000 Single finger livesca

Specifications
Platen area: L0.65” x W0.83” (16. 4mm x 21.1mm)
Active platen area: L0.6” x W0.8” (15.24mm x 20.32mm)
L300 * W400 pixels
Resolution: 500dpi±1%
Image distortion: ≤1%
Image gray range: ≥210 grayscales
Grayscale: 8-bit, 256 levels
Connecter/Power: USB 2.0
Dimension: L56 x W31.5 x H13.4mm (D2000 Module)
L59.1 x W48.5 x H18.5mm (DF200S Device)

Environmental Durability：IP65 (Dust and Water Resistant), -10°C to 50°C , 0.85% humidity

Supported Fingerprint Template Formats: ISO 19794-2, ANSI 378.

Fingerprint template matching: Supports on-chip tingerprint template matching for 1:1 verification. (Optional)

PC requirement:
Win7, Win10, 32 or 64bits;
1.7GHz CPU, 1G RAM, 80G disk, USB 2.0 compliant ports at least.

Android Requirement：
Android 4.1 or Higher

Certifications:
FBI Standard CJIS IAFIS Image Quality Specifications (IQS) for Personal Identity Verification
(PIV) Mobile ID FAP 20
